Technical Specifications
[ ] Optional
Pallet size [mm]
400 x 400
Axis travel [mm]
X: 560 / Y: 640 / Z: 640
Spindle speed [min-1]
14,000 [14,000 High Torque], [20,000]
ATC Capacity [tools]
60 [134], [219], [313]
Maximum Workpiece [mm]
Ø630 x 900
Pallet size [mm]
500 x 500
Axis travel [mm]
X: 730 / Y: 650 [730] / Z: 800
Spindle speed [min-1]
14,000 [20,000]
ATC Capacity [tools]
60 [133], [218], [313]
Maximum Workpiece [mm]
Ø800 x 1,000
Pallet size [mm]
500 x 500
Axis travel [mm]
X: 800 / Y: 750 / Z: 830
Spindle speed [min-1]
10,000
ATC Capacity [tools]
60 [136], [187], [299]
Maximum Workpiece [mm]
Ø900 x 1,000
Pallet size [mm]
630 x 630
Axis travel [mm]
X: 900 / Y: 900 / Z: 1,020
Spindle speed [min-1]
10,000 [8,000 High Torque]
ATC Capacity [tools]
60 [80], [136], [187], [299]
Maximum Workpiece[mm]
Ø1,000 x 1,300
Pallet size [mm]
800 x 800
Axis travel [mm]
X: 1,400 / Y: 1,200 / Z: 1,350
Spindle speed [min-1]
10,000 [8,000 High Torque], [15,000]
ATC Capacity [tools]
60 [185], [297]
Maximum Workpiece [mm]
Ø1,450 x 1,450
Pallet size [mm]
1,000 x 1,000 [1,250 x 1,000]
Axis travel [mm]
X: 1,900 / Y: 1,600 / Z: 1,700
Spindle speed [min-1]
8,000 [20,000]
ATC Capacity [tools]
204
Maximum Workpiece [mm]
Ø2,100 x 1,800
